Advanced Road Design

Advanced Road Design 2011 (x32 and x64)

Advanced Road Design (ARD) has been developed to provide Australian based road and drainage design and outputs inside AutoCAD Civil 3D. Built for the AutoCAD Civil 3D design environment, ARD features a streamlined design interface to merge seamlessly with AutoCAD Civil 3D and work with the Civil 3D civil objects. Centralised design tools make it easy for you to edit any design element without having to search through multiple commands or run sequential routines.


Road Design
With the ARD Vertical Design Windows you get complete access to any selected design element including editing the vertical design and cross sections, establish cut/fill bulking factors, generate summary volume reports and create surface models of your designs.

Drainage Design
Simple to use layout and editing tools are included so you can create and adjust your pits and pipes as required. Creating pits and pipes is made easy with options to click on screen or create directly from polylines and alignments.
Easily create drainage catchments directly from the digital terrain in Civil 3D and a polyline – catchment style libraries allow you to easily assign catchment criteria for common catchment types.
When a network is created the design flows are calculated and pipe sizes and levels are automatically assigned to manage the flows as well as minimum cover, slope and flow velocities.

Pipe Design
Create and layout your sewer network by either clicking on screen or create directly from polylines or alignments. Whilst the initial pipe layout is based on minimum slopes and covers, the multiple Vertical Design Windows allow you to quickly adjust any pipe sizes and levels to achieve your desired outcomes.

Sewer Design
Create and layout your sewer network by either clicking on screen or create directly from polylines or alignments. Editing tools match those in the drainage module to enable you to readily change pipe and pit properties.
Sewer house/property connections are included to check for depth controls and minimum levels along the sewer network. Each house connection can be viewed in a Vertical Design window for editing and adjustment.
The sewer network will automatically adjust to ensure compliance with the minimum house connection levels, and the user will be alerted as sewer pipe edits result in any compliance issues with house/property connections.


Install standalone, Comercial.
Run RLM.EXE, Allow access in Firewall amd leave it open.
The license and the other two files have to be together in one folder.
Tested in Windows 7 64 bit and using Civil 3D 64 bit.
I can't tell more about resultats because this is not my speciality and i don't use Civil 3D.
